Kentec Safe-Point 8-Way Disabled Refuge Control Panel - Loop Wired - Flush Mounting (K41208FST)

The Kentec Safe-Point K41208FST is an 8-way disabled refuge (emergency voice communication) master control panel for loop wiring and flush mounting. It lets staff answer or call up to eight Safe-Point disabled refuge outstations.

The outstations are wired to the master panel in a loop, which cuts installation time and cost. The cabinet has space for 7 Ah batteries, giving the 24 + 3 hours standby specified by BS 5839 Part 9. It has a stainless-steel fascia on a mild-steel back box.

Key features

• 8 call/answer outstation inputs, loop wired
• Simple handset operation with full-duplex conversation; calls end when the handset is replaced
• Call or answer each, several or all outstations from the fascia push buttons
• Alarm indicators with internal buzzer; power on and system fault indicators
• Lamp test and buzzer silence push button
• 'In Fire' enable input to prevent non-essential calls
• Integrated display for custom alarm information
• Tamper-resistant vision window cover
• Toilet alarm kits can be wired in line with a refuge call/answer point

Technical specifications

• Product code: K41208FST (flush, loop)
• Enclosure: stainless-steel fascia, mild-steel back box
• Flush back box: 460 (W) x 360 (H) x 98 (D) mm
• Flushing flange: 510 x 410 mm
• Batteries: space for 7 Ah (24 + 3 hours standby to BS 5839-9)
• Weight: 3 kg
