Nittan Evolution SCI-6 Wall Mounted Short Circuit Isolator (S.C.I.-6)
SKU: S.C.I.-6Brand: Nittan
Key featuresFull details
- Non-addressable ("dumb") wall-mounted short circuit isolator
- Solid-state switching between the incoming and outgoing SIG+ wires
- Limits a short circuit fault to the cable between two adjacent isolators
- Yellow/amber LED indicates a short circuit cable fault
- Terminals for loop in/out and screen continuity
- Fits any single-gang surface or flush electrical box (matching back box available separately, F16-81442)
| Available to order | Qty | Delivery |
|---|---|---|
| Pre-order | 0 | Lead time 2 to 6 weeks |
Nittan Evolution SCI-6 Wall Mounted Short Circuit Isolator (S.C.I.-6)
£25.10
Genuine stockBrand new, boxed
1 year warrantyPlus statutory rights
Secure checkoutEncrypted payments
Trade accounts30 day credit
Frequently bought together
Nittan
Nittan LED Remote Indicator (No Back Box) (STA-R1)
Sale price£8.60
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Nittan
Nittan Manual Call Point Reset Keys (Pack of 10) (RPK-10)
Sale price£12.55
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Nittan
Nittan Outer Cover (for UG-3 Duct Probe) (UG-Cover-IP54)
Sale price£267.95
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Nittan
Nittan Sensortec Addressable Heat Detector (ST-H2-AS)
Sale price£54.80
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Product details
The Nittan SCI-6 is a wall-mounted short circuit isolator for Nittan analogue addressable fire alarm loops. Fitted between sections of loop wiring, it isolates the section containing a short circuit so the rest of the loop can continue to operate. It is built into a single-gang plate that fits a standard single-gang surface or flush box.
Key features
- Non-addressable ("dumb") wall-mounted short circuit isolator
- Solid-state switching between the incoming and outgoing SIG+ wires
- Limits a short circuit fault to the cable between two adjacent isolators
- Yellow/amber LED indicates a short circuit cable fault
- Terminals for loop in/out and screen continuity
- Fits any single-gang surface or flush electrical box (matching back box available separately, F16-81442)
Specification
| Product code | SCI-6 |
|---|---|
| Nittan part number | F16-81440 |
| Brand | Nittan |
| Rating | 24V nominal |
| Quiescent current | 300µA approx. |
| Operated current | 15mA |
| Operating temperature | -10°C to +50°C |
| Dimensions (plate only) | 85mm W x 15mm D (21mm with terminals) x 85mm H |
Datasheet
Nittan Evolution SCI-6 Wall Mounted Short Circuit Isolator (S.C.I.-6) Need the datasheet? Our team will email it to you. Request datasheet
