The Comelit PAC 909032059 is a DIN-rail 12 V DC power supply with built-in battery charger, rated 50 W, for PAC access control systems and 12 V DC door locks. It meets the California Energy Commission (CEC) Level 6 efficiency standard, with around 80% efficiency at most loads, and battery charger leads are supplied so a standby battery can be connected.
Key features
- DIN-rail mounting
- 12 V DC battery charger with leads supplied
- CEC Level 6 certified, about 80% efficiency at most load levels
- For 12 V DC door locks; battery back-up needs one 7 Ah 12 V battery (not included)
Technical specifications
- Part number: 909032059
- Input: 100-230 V AC, 50/60 Hz
- Output: 13.8 V at 3.3 A
- Rating: 50 W
- Efficiency: level VI (CEC)
- Dimensions: 90 x 176 x 50 mm (W x H x D)
- Weight: 0.7 kg
- Operating temperature: -20 °C to +50 °C
- Warranty: 5 years against electronic failure
- Standards: UKCA, CE, UL, FCC, IC, RoHS and WEEE; CEC level 6
