| Application/Usage |
Expand network's bandwidth and reduce traffic bottlenecks; Networking PoE devices such as high-power wireless access points, cameras, digital signage, IPTV decoders, access controls |
| Bandwidth |
40Gbps |
| Cable Type |
Cat5e |
| Compatibility |
10/100/1000Mbps devices; PoE/PoE+/PoE++ devices |
| Data Transfer Rate |
20Mbps |
| Depth |
105.00mm |
| Device Supported |
Access controls; Cameras; Digital signage; IPTV decoders; wireless access points |
| Features |
230W PoE power budget; 40Gbps switching capacity; 8 x 2.5G PoE++ ports; Backwards compatible with 10/100/1000Mbps devices; Compatible with existing Cat5e or better cabling; Fanless design eliminates noise; IEEE 802.3bz (2.5G) compliant; NDAA / TAA compliant (U.S. and Canada only); Supports IEEE 802.3af/at/bt; Wall mountable for installation flexibility |
| Height |
27.00mm |
| Input Voltage |
100-240V AC |
| Limited Warranty |
Lifetime |
| Material |
Metal |
| Maximum Data Transfer Rate |
2.5Gbps |
| NDAA Compliant |
Yes |
| Number of Network (RJ-45) Ports |
8 |
| Number of Ports |
8 |
| Output Voltage |
54V |
| Package Contents |
Power brick (54V, 4.7A); Power cord (1.5m / 4.9 ft.); Quick Installation Guide; TPE-BG380 |
| PoE |
Yes |
| PoE Budget |
230W |
| Power Source |
AC Power |
| Product Series |
Version V1 |
| Product Type |
Multi-Gigabit PoE++ Switch |
| TAA Compliant |
Yes |
| Total Number of Network Ports |
8 |
| Weight |
716.00g |
| Width |
240.00mm |
| Maximum Operating Temperature |
40°C |
| Additional Warranty Information |
Lifetime Warranty |
| Buffer |
1MB |
| Certifications & Standards |
CE; FCC; IEEE 802.3; IEEE 802.3ab; IEEE 802.3af; IEEE 802.3at; IEEE 802.3bt; IEEE 802.3bz; IEEE 802.3u; IEEE 802.3x |
| Dimensions |
240mm x 105mm x 27mm |
| Input Current |
4A |
| Interfaces/Ports Details |
C; USB type A |
| LED Indicator |
Status |
| Maximum Power Consumption |
9.50W |
| Minimum Operating Temperature |
0°C |
| MTBF |
288800hr |
| Number of Ethernet Ports |
8 |
| Operating Humidity |
90% (Non-condensing) |
| Power over Ethernet (PoE) |
Yes |
| Power Supply |
AC |
| RoHS Compliant |
Compliant |
| WEEE Compliant |
Out of Scope |
