The Videx 8851/BL is a 1 module 8000 series front support frame and flush back box, with the front frame in a black finish. It is used to flush mount Videx 8000 series audio and video door entry modules.
Flush back boxes can be joined together with the spacers provided when a panel needs more than three modules (for example, two 8852 boxes for a four module panel), and can be combined with 8000 series rainshields to cover cut-outs in the wall.
Key features
- Houses 1 module of the 8000 series
- Front support frame in black finish; white high impact ABS flush back box
- Waterproof gasket fitted to the front support frame
- Spacers provided to join back boxes for panels of more than 3 modules
- Compatible with all 8000 series audio and video modules, except the CVK8K and CVKC8K video modules (8833-1/C and 8833-2/C)
- Matching rainshield: 8871
Technical specifications
- Part number: 8851/BL
- Housed module size: 1 module
- Front support frame size: 115 (W) x 154 (L) x 22 (D) mm
- Flush back box size: 115 (W) x 144 (L) x 30 (D) mm
- Front support frame finish: black
- Flush back box material: white, high impact ABS plastic
What's in the box
- Front support frame and flush back box
- Waterproof gasket, fixing brackets, hinge screws and central Allen key screw
- Spacers for joining back boxes
