The Videx 6276 is a 6200 series colour videophone with handset for the Videx VX2200 digital door entry system. It has a 3.5" high resolution colour LCD screen in a compact satin white housing, and is also used with 6-wire bus C4KVID (non-coax) and CVR4KV (non-coax) series videokits.
Four buttons give camera recall, door open and concierge call, privacy on/off and a spare service function. It can be wall mounted or placed on a desk with the 62931 desktop kit.
Key features
- 3.5" hi-res colour LCD TFT screen with handset
- 4 buttons: camera recall, door open and concierge call, privacy on/off, spare service
- 2 LEDs for privacy on/off and door open
- Timed or manual privacy
- 3 level call tone volume switch
- Programmable number of rings, melody and privacy time
- Wall mount or desktop kit (62931)
- Memory version available (6276/MV) storing up to 100 pictures with date and time
Technical specifications
- Part number: 6276
- System: VX2200 digital
- Display: 3.5" hi-res colour LCD TFT
- Handset/hands-free: handset
- Adjustments: call tone volume (3 levels), mic volume, contrast, hue and brightness; video mode (coax or balanced) and video termination
- Programmable features: number of rings (6 or 3), melody (9 max.), privacy time (15 minutes to 20 hours, or manual), videophone address (ID)
- Inputs: local bell, alarm input and door open LED
- Video signal: balanced (V1/V2) or coax (V/M)
- Power supply input: 20 VDC (supplied by 893N PSU)
- Power consumption: 2 mA standby, 200 mA in operation, 250 mA peak
- Working temperature: -20 °C to +60 °C
- Finish: satin white
- Dimensions: 144 (W) x 182 (H) x 27 (D) mm
