VR/DINBIOC is a Videx panel option that builds a Portal Plus DINBIOC fingerprint reader into a Videx vandal resistant door panel, such as the VR120 series or the SP300/SP301 digital panels. The reader has a Wiegand output and RS485 connection for use with the Portal Plus access control system or other Wiegand-based access control.
Adding the reader increases the overall panel size.
Key features
- Biometric fingerprint reader integrated into a VR panel
- Capacitive fingerprint sensor
- Stores up to 9500 fingerprint templates
- Wiegand 26 bit and RS485 outputs
- Fingerprint enrolment is built into the Portal Plus PROS CS software
Technical specifications
- Option code: VR/DINBIOC (DINBIOC reader electronics)
- Operating voltage: 12 VDC
- Current consumption: 200 mA max.
- Biometric sensor: capacitive
- Fingerprint templates: 9500
- Output: Wiegand (26 bit), RS485
- Operating temperature: 0 °C to +40 °C
