VR/DINMTPX-MF-E is a Videx panel option that builds a Portal Plus DINMTPX-MF-E Mifare proximity reader into a Videx vandal resistant door panel, such as the VR120 series or the SP300/SP301 digital panels. The reader has a Wiegand 26 or 34 bit output for the Portal Plus access control system or other Wiegand-based access control.
Adding the reader increases the overall panel size.
Key features
- Mifare proximity reader integrated into a VR panel
- Reads Mifare Classic CSN, Ultralight and Desfire (13.56 MHz)
- Wiegand 26 or 34 bit output
- Read range up to 7 cm
Technical specifications
- Option code: VR/DINMTPX-MF-E (DINMTPX-MF-E reader electronics)
- Operating voltage: 12 VDC
- Current consumption: 150 mA max.
- Operating frequency: EM4100 125 kHz, Mifare Desfire 13.56 MHz
- Read range: 7 cm max.
- Reader output: Mifare Classic CSN, Ultralight and Desfire; Wiegand 26 or 34 bit
- Wiring: terminal block
- Operating temperature: -20 °C to +50 °C
