The Videx 8203-2 is a two-button functional audio speaker module for the Videx VX2200 digital door entry system, in the modular 8000 series format. It contains the speaker and a fly-lead microphone, and its dry contact relay can switch an electric lock or trigger gate or barrier controls.
Calls can be expanded to a total of 64 buttons using 8000 series button modules, and the module can be connected to an 8830 camera module.
Key features
- Audio speaker module for the VX2200 digital bus system
- 2 built-in call buttons with back-lit blue name plates
- Expandable up to 64 call buttons with 8842, 8843, 8844, 8845, 8842D, 8843D, 8844D and 8845D button modules
- Separate adjustment for microphone, speaker and speech balance
- Dry contact relay (C/NO/NC) for a lock or gate/barrier control
- Can be connected to an 8830 camera module
- Mirror stainless steel front fascia
- Backwards compatible with older Videx 800 series front support frames (surface and flush)
Technical specifications
- Part number: 8203-2
- System: VX2200 digital
- Built-in buttons: 2 (tactile microswitch), name plates back-lit blue
- Programming (SW1): master/slave, push-button group, conversation time, door open time, unit ID (1 to 8)
- Relay: 1 x dry contact (C/NO/NC), 24 VAC/DC, 2 A max.
- Push-to-exit input: no
- Working voltage: +13 VDC ±10% (compatible PSUs: 521 and 521B)
- Power consumption: 60 mA standby, 350 mA max. during operation
- Working temperature: -10 °C to +50 °C
- Module size: 97 (W) x 120 (L) x 30 (D) mm (1 module 8000 series)
