The Videx VR4KPROXM is a vandal resistant 4000 series proximity reader cut-out module, designed to house a third-party panel mount proximity reader in a Videx VR4K or 4000 series door entry panel. It suits readers with a 40 x 40 mm square front fascia and 49 x 49 mm square mounting hole positions. No reader is supplied.
It is made from 12 gauge, 316 grade vertically brushed stainless steel and fits the full range of 4000 series surface and flush back boxes.
Key features
- 12 gauge, 316 grade brushed stainless steel fascia
- IK09 impact protection and IP55 ingress protection
- 40 x 40 mm square reader cut-out
- Four M3 stud fixings at 49 x 49 mm spacing
- Fits all 4000 series surface and flush back boxes
Technical specifications
- Part number: VR4KPROXM
- Reader compatibility: third-party panel mount readers with a 40 x 40 mm square fascia and 49 x 49 mm square mounting holes (4 mm diameter)
- Cut-out: 40 x 40 mm square with four M3 x 20 stud fixings at 49 x 49 mm spacing
- Fixings: includes 4 x M3 flat washers and 4 x M3 fixing nuts
- Protection: IK09 impact, IP55 ingress
- Module dimensions: 103 (W) x 120 (L) x 22 (D) mm
