The Videx VR4KVPM is a vandal resistant 4000 series EM proximity reader module for the Videx VProx access control system. It reads 125 kHz EM (4002/4100) fobs and cards and works with the full range of VProx CPUs: VP20, VP100, VP250, VP1000, VP4000 and the 1000A expansion reader module. A VProx controller is required.
It is made from 12 gauge, 316 grade vertically brushed stainless steel and fits the full range of 4000 series surface and flush back boxes.
Key features
- 12 gauge, 316 grade brushed stainless steel fascia
- IK09 impact protection and IP55 ingress protection
- Tri-colour status LED: green (access granted), red (access denied), amber (idle)
- Read range up to 5 cm at 125 kHz
- Pre-wired cable connection
- Fits all 4000 series surface and flush back boxes
Technical specifications
- Part number: VR4KVPM
- Compatible VProx CPUs: VP20, VP100, VP250, VP1000, VP4000 and 1000A reader expansion module
- Operating frequency: 125 kHz, EM 4002/4100
- Read range: up to 5 cm
- Compatible fobs/cards: 955/T, 955/B, 955/R, 955/Y, 955/G fobs and 955/C card
- Power input and current: 12 VDC, 80 mA (standby), 120 mA (during operation)
- Protection: IK09 impact, IP55 ingress
- Module dimensions: 103 (W) x 120 (L) x 22 (D) mm
