The Advanced LXP-901 is a plug-in PuLsE loop driver card for the LuxIntelligent automatic emergency lighting test panel. Each loop driver adds one addressable loop to the panel, which supports 1 to 4 loops.
LuxIntelligent is an addressable emergency lighting control system that automatically tests maintained, non-maintained and slave luminaires in self-contained, central battery or static inverter systems, and keeps the results for inspection and audit to BS 5266-1 and EN 50172.
Key features
- Plug-in card adding one PuLsE loop to the LuxIntelligent panel
- Loop-powered communications to luminaires and modules
- Up to 249 devices per loop
- Panel supports 1 to 4 loops and up to 996 luminaires
Technical specifications
-
Protocol: PuLsE
-
Devices per loop: 249
-
Loop current: 500mA
-
Panel loop capacity: 1 to 4 loops
-
Panel capacity: 996 luminaires, 200 zones across 4 loops
