The Advanced MXP-024 is a 20-zone LED card and label for the Advanced MxPro 4 1-loop control panel (MX-4100). It fits to the front display plate and provides individual LED indication of the zones in fire, in addition to the panel's graphical display. This is the retrofit version of the MXP-024F.
Key features
- 20 individual zone fire LEDs
- Can display all zones in fire simultaneously
- Power-saving feature to minimise current draw in a major fire
- Supports dynamic zoning on networked or larger standalone systems
- Retrofit version (MXP-024F is the fitted version)
Technical specifications
-
Part number: MXP-024
-
Zones: 20
-
Supplied as: LED card and label, retrofit
-
Compatibility: MxPro 4 1-loop control panel (MX-4100)
