The Advanced MXS-006 is a spare power supply unit for the MxPro 4 Mx-4200 1-2 loop analogue addressable fire alarm control panel. The Mx-4200 is now obsolete, and this spare allows existing installations to be maintained.
Key features
- Genuine Advanced spare for the MxPro 4 Mx-4200
- Mx-4200 on-board power supply: 4A high-efficiency switched mode
- Mx-4200 charger: 2.0A DDP monitored, temperature compensated
Technical specifications
-
Part code: MXS-006
-
For use with: Mx-4200 1-2 loop panel
-
Panel on-board power supply: 4A high-efficiency switched mode
-
Panel mains supply: 230V AC (+10% / -15%), 50/60Hz, 1.9A
-
Panel charger current: 2.0A, DDP monitored, temperature compensated
-
Panel battery capacity: 24V 18Ah internal
-
Panel auxiliary supply: 1 x 24V 500mA
