Featuring a stereographic lens and Sharpdome 360, this panoramic camera delivers greater sharpness at the edges of the image. With a 6 MP sensor, it offers excellent image quality and a complete 180° or 360° overview, around the clock regardless of the light conditions. Plus, Lightfinder ensures lifelike colors in low light. With day/night functionality and built-in IR illumination with individually controllable LEDs, it delivers clear, reflection-free footage and excellent image quality even in low light or complete darkness. Furthermore, AXIS M4317-PLVE supports digital PTZ views as well as dewarped views such as panorama, quad, corner, and corridor.
Main Features
Complete 180° and 360° overview
Built-in IR with individual IR LEDs
Support for deep learning analytics
Built-in cybersecurity features
Digital roll for ease of installation
Specifications
Connectivity Technology
Wired
Diameter
149.0mm
Durability
Vandal Resistant
Effective Camera Resolution
6MP
Environmental Certification
IEC 60068-2-1; IEC 60068-2-14; IEC 60068-2-2; IEC 60068-2-27; IEC 60068-2-6; IEC 60068-2-78; IEC/EN 60529 IP66; IEC/EN 62262 IK10; ISO 21207 (Method B); ISO 4892-2; NEMA 250 Type 4X; NEMA TS 2 (2.2.7-2.2.9)
Environmentally Friendly
Yes
Features
Built-in IR LED; Day/Night; Human Detection; Motion Detection; Noise Reduction; PTZ; Tampering Alarm; Vehicle Detection; Video Management System; White Balance; Wide Dynamic Range
Field of View
Horizontal; Vertical
Focal Length
1.1mm
Form Factor
Dome
Height
70.0mm
Image Sensor Type
CMOS
Indoor/Outdoor
Outdoor
Ingress Protection Rating
IP66
Lens Type
Fixed
Limited Warranty
3-Year
Maximum Aperture
f/2.2
Maximum Focal Length
1.1mm
Maximum Resolution
1280 x 720
Mount Type
Gang Box Mount; Junction Box Mount; Surface Mount; Tripod Mount
