| American Wire Gauge |
23AWG |
| Application/Usage |
Horizontal and building backbone cable; Support current and future Category 6A and 6 applications, such as: 10GBase-T (10 Gigabit Ethernet), 1000Base-T (Gigabit Ethernet), 100 Base-T, 10 Base-T, FDDI, ATM |
| Cable Length |
500m |
| Cable Type |
S/FTP |
| Compatibility |
Category 6; Category 6A |
| Conductor Count |
8 |
| Conductor Material |
Bare Copper |
| CPR Euroclass Rating |
Cca-s1a,d1,a1 |
| Data Transfer Rate |
10Gbps |
| Diameter |
7.2mm |
| Environmental Certification |
Halogen Free Compliance; RoHS Compliant |
| Environmentally Friendly |
Yes |
| Features |
100% Individual Pair Shield Coverage; 23 AWG Solid Bare Copper; 30% Overall Braid Coverage; 625MHz Bandwidth; CPR Euroclass Cca-s1a,d1,a1; LSZH Flame Retardant Jacket; PoE Support up to 100W; S/FTP Shielding |
| Impedance |
100Ohm |
| Indoor/Outdoor |
Indoor |
| Insulation Material |
PE (Polyethylene) |
| Jacket Material |
LSZH (Low Smoke Zero Halogen) |
| Material |
Bare Copper |
| Number of Conductors |
8 |
| Number of Pairs |
4 |
| Package Type |
Reel/Spool |
| Product Line |
10GX |
| Product Type |
PoE Cable |
| Shielding |
Yes |
| Solid or Stranded |
Solid |
| Voltage Rating |
72V DC |
| CE Marking |
Yes |
| Certifications & Standards |
ANSI/TIA 568.2-D; EN 50173-1; IEC 60332-1-2; IEC 60754-1; IEC 60754-2; IEC 61034-2; IEC 62821-1; IEEE 802.3bt Type 1, Type 2, Type 3, Type 4; ISO/IEC 11801-1 |
| Colour |
Blue |
| Localization |
English |
| Operating Temperature (T-T) |
-30-60°C |
| RoHS Compliant |
Compliant |
| UKCA Marking |
Yes |
| WEEE Compliant |
Out of Scope |
