C-TEC 5 Series 24V 3A EN54-4 Metal Boxed PSU (2 x 12V 18Ah Max) (BF562-3)

The C-TEC BF562-3 is a 24V 3A switch mode/digital hybrid power supply in a metal enclosure, certified to EN54-4/A2 by the LPCB and VdS. It is ideal for powering beam detectors, auto-dial communicators, aspirating smoke detectors, auto-open vent systems, auxiliary sounder systems or any other device performing a mandatory function of a fire alarm system.

Key features

• Certified to EN54-4/A2 by the LPCB and VdS
• Single-pole volt-free changeover relay that switches on any fault condition
• Supply present, general fault, fault type and auxiliary equipment fault indicators
• Two selectable battery charge currents
• Battery resistance monitoring to EN54-4/A2
• Mains fail simulation mode
• On-board temperature sensor, with an optional BF322 remote battery temperature sensor
• Can be customised with a BF423 configurator and PC (changing parameters takes the PSU outside the scope of EN54-4)
• Electronic functions comply with EN50131-6 grades 1-4 for security applications

Technical specifications

• Output: 24V DC, total output current limited to 3A
• I max.a: 2.6A or 2A selectable; I max.b: 3A (charging turned off)
• Mains supply: 230V 50/60Hz, rated current 0.8A r.m.s.
• Battery charge capacity: 2Ah to 17Ah
• Batteries: 12V VRLA, 2.5Ah to 17Ah (approved: Yucel Y Series 7Ah to 17Ah)
• Indicators: 3 external (Supply Present, General Fault, Auxiliary Fault) and 2 internal (Hazardous Voltages Present, PSU Status)
• Connections: mains input, supply output, battery input, fault relay, charge off input; remote thermistor via PL3
• Dimensions: 404mm (W) x 404mm (H) x 110mm (D)
• Construction: metal lid and base, RAL7035 textured finish
• IP rating: IP30 (indoor use only)
• Weight: 5kg (without batteries)
• Operating temperature: -5°C to +40°C, max. 95% relative humidity
