C-TEC CAST Manual Call Point Universal Mount Blue
£36.90
Genuine stockBrand new, boxed
1 year warrantyPlus statutory rights
Secure checkoutEncrypted payments
Trade accounts30 day credit
Key featuresFull details
- Blue version of the CA470 CAST manual call point
- For C-TEC XFP and ZFP CAST protocol addressable fire panels
- Surface or flush mountable (supplied with a surface back box and flush mount adaptor plate)
- Onboard short-circuit loop isolator
- Smooth-action resettable element that mimics the feel of breaking glass
- Red LED 'alarm ring' lights the call point face when activated
Product details
The C-TEC CA470B is the blue version of C-TEC's CA470 CAST manual call point with universal (surface or flush) mounting. It is an addressable device for C-TEC's XFP and ZFP fire panels that use the CAST protocol, and it has an onboard short-circuit loop isolator.
Key features
- Blue version of the CA470 CAST manual call point
- For C-TEC XFP and ZFP CAST protocol addressable fire panels
- Surface or flush mountable (supplied with a surface back box and flush mount adaptor plate)
- Onboard short-circuit loop isolator
- Smooth-action resettable element that mimics the feel of breaking glass
- Red LED 'alarm ring' lights the call point face when activated
- Photoluminescent operating window remains visible for up to 5 minutes
- Supplied with a reset/back box removal key and 'Not in Use' label
Technical specifications
- Order code: CA470B
- Colour: Blue
- Protocol/compatibility: C-TEC CAST (XFP/ZFP CAST protocol addressable fire panels)
- Supply voltage: 22 to 40V DC
- Quiescent current: 370µA typical @ 22 to 40V DC
- Alarm current: 5mA typical @ 22 to 40V DC
- Indicators: Red 'alarm ring': steady red when activated, flashing red when polling
- Connections: Loop IN, Loop OUT (x2)
- Dimensions: 87 W x 88 H x 62 D mm (including back box)
- Construction: ABS polycarbonate with glass fibre window
- IP rating: IP42
- Weight: 180g
- Operating temperature: -10ºC to +55ºC
What's in the box
- Manual call point with surface back box and flush mount adaptor plate
- Reset/back box removal key
- 'Not in Use' label
Datasheets & documents
No datasheet is online for this product yet. Ask us and we will email it to you.
