C-TEC CAST Manual Call Point Universal Mount White

SKU: CA470WBrand: C-TEC
4.6store rating from 122 reviews
Out of stock Qty Delivery
All locations0Lead time 2 to 6 weeks, estimate only
Need help choosing? Our UK team can check compatibility, stock and project pricing for you. 0117 440 4505info@jemsystems.co.uk
Price:
Sale price$49.00
58.80 inc. VAT49.00 ex VAT
Stock:
Out of stock. Lead time 2 to 6 weeks, estimate only
Delivery
Out of stock
Lead time 2 to 6 weeks, estimate only
Collect in Poole
Not stocked in Poole
Delivery only
C-TEC CAST Manual Call Point Universal Mount White $49.00
Genuine stockBrand new, boxed
1 year warrantyPlus statutory rights
Secure checkoutEncrypted payments
Trade accounts30 day credit
American Express Apple Pay Google Pay KlarnaMaestroMastercard PayPalShop Pay Visa
Key featuresFull details
  • White version of the CA470 CAST manual call point
  • For C-TEC XFP and ZFP CAST protocol addressable fire panels
  • Surface or flush mountable (supplied with a surface back box and flush mount adaptor plate)
  • Onboard short-circuit loop isolator
  • Smooth-action resettable element that mimics the feel of breaking glass
  • Red LED 'alarm ring' lights the call point face when activated

Frequently bought together

C-TEC CAST Programmable Heat Detector
C-TEC CAST Wall Sounder Shallow Red

Product details

The C-TEC CA470W is the white version of C-TEC's CA470 CAST manual call point with universal (surface or flush) mounting. It is an addressable device for C-TEC's XFP and ZFP fire panels that use the CAST protocol, and it has an onboard short-circuit loop isolator.

Key features

  • White version of the CA470 CAST manual call point
  • For C-TEC XFP and ZFP CAST protocol addressable fire panels
  • Surface or flush mountable (supplied with a surface back box and flush mount adaptor plate)
  • Onboard short-circuit loop isolator
  • Smooth-action resettable element that mimics the feel of breaking glass
  • Red LED 'alarm ring' lights the call point face when activated
  • Photoluminescent operating window remains visible for up to 5 minutes
  • Supplied with a reset/back box removal key and 'Not in Use' label

Technical specifications

  • Order code: CA470W
  • Colour: White
  • Protocol/compatibility: C-TEC CAST (XFP/ZFP CAST protocol addressable fire panels)
  • Supply voltage: 22 to 40V DC
  • Quiescent current: 370µA typical @ 22 to 40V DC
  • Alarm current: 5mA typical @ 22 to 40V DC
  • Indicators: Red 'alarm ring': steady red when activated, flashing red when polling
  • Connections: Loop IN, Loop OUT (x2)
  • Dimensions: 87 W x 88 H x 62 D mm (including back box)
  • Construction: ABS polycarbonate with glass fibre window
  • IP rating: IP42
  • Weight: 180g
  • Operating temperature: -10ºC to +55ºC

What's in the box

  • Manual call point with surface back box and flush mount adaptor plate
  • Reset/back box removal key
  • 'Not in Use' label
