This digital 7-day timer module is ideal for setting up free access periods in environments such as schools and universities, for class changeover times and mass entry/exit events. With an LCD digital display for simple programming, and up to 8 on/off schedules that can run daily or weekly, the TH827-12 is a flexible, handy module for a wide variety of projects. The timer operates automatically but also includes a manual override function - just in case!
Main Features
7-day digital timer module
8 on/off schedules - run daily or weekly
LED indication and LCD screen
200 hours battery backup in case of power failure
Ideal for free access unlocking periods - such as for school entry/exit times
Specifications
Depth
34.00mm
Features
200 hours battery backup; Daily or weekly schedules; LCD screen; LED Indication
Height
60.00mm
Identification Method
Contactless Card (RFID/Proximity)
Input Voltage
12V AC/V DC
Limited Warranty
5-Year
Material
Plastic
Mount Type
Surface Mount
Packaged Quantity
1
Product Series
TH
Product Type
Digital Timer
Width
60.00mm
Additional Information
For power supplies, Digicode® keypads and telephone panels
