The Edwards 4-NET-SM is a small form-factor pluggable (SFP) network controller for the Edwards EST4 life safety control platform (EN54 version), for panel-to-panel connections over single-mode, dual-fibre optical cable. EST4's self-configuring IPv6 network carries all panel-to-panel services on a single network cable, so no separate audio riser or telephone interconnections are needed.
Key features
- Plugs into the SFP network slots on the 4-CPU-E (two per CPU) and other EST4 network devices
- Hot-swappable network connection
- Carries panel data, voice audio and firefighters' telephone on the same cabling
- Choose the SFP to match the installed cable - media can differ between panels
Technical specifications
- Media: single-mode, dual-fibre
- Standard: 100Base-LX10
- Wavelength: 1310 nm
- System: EST4 (4-CPU-E network ports)
- Data sheet reference: E85014-0008
