Edwards 4-NET-SMU Single-Mode Fiber-Optic SFP Network Controller Bi-Directional

The Edwards 4-NET-SMU is a bi-directional single-mode, single-fibre SFP network controller (uplink) for the Edwards EST4 life safety control platform. It links panels over one 9/125 µm (G.652) single-mode fibre up to 10 km, and must be paired with a 4-NET-SMD (downlink) at the other end.

EST4 4-NET series controllers are hot-swappable SFP transceivers that set the physical cable type between panels. They plug into either of the two SFP slots on the 4-CPU, 4-ANNCPU, 4-CPUGRPH and 4-NET-AD modules, and one network cable carries panel data, voice audio and firefighters' telephone. If a connected CPU goes offline, the input and output ports connect directly to each other, keeping basic network connectivity.

Key features

• Hot-swappable SFP network controller
• Carries panel data, voice audio and firefighters' telephone on the same fibre
• Pass-through mode keeps connectivity if a panel CPU goes offline
• Self-configuring IPv6 network; supports Class A, B, X and N configurations
• Can be mixed with copper, CAT5 and other fibre controllers on the same network
• Uses a single fibre for both directions, paired with a 4-NET-SMD

Technical specifications

• Model: 4-NET-SMU
• Transceiver type: 100Base-BX10-U, single fibre, uplink
• Wavelength: 1310 nm transmit / 1550 nm receive
• Pairs with: 4-NET-SMD
• Fibre: single-mode 9 µm (G.652), one fibre
• Maximum cable distance: 10 km (6.2 miles)
• Transmit power: -14 to -8 dBm; receive power: -27 to -8 dBm
• Maximum channel insertion loss: 5 dB
• Connector: LC simplex
• Data speed: 100 Mbps TX/RX
• Current (standby/alarm): 5 mA at 24 VDC
• Operating temperature: 0 to 49°C; 0 to 93% RH non-condensing
• Agency listings: UL, ULC, FM, CSFM, EN54, CE, NYC Fire Dept.
• Shipping weight: 0.112 kg
• System: EST4
• Data sheet reference: E85014-0008
