EMS SmartCell Wireless Dual Smoke/Heat Detector with Sounder VAD (Red Flash) (SC-23-0210-0001-99)

The EMS SmartCell Wireless Dual Smoke/Heat Detector with Combined Sounder and Beacon (VAD, red flash), part number SC-23-0210-0001-99, combines smoke and heat detection, a 32-tone sounder and an EN54-23 visual alarm device in a single battery-powered wireless unit for the SmartCell wireless fire system.

Detection can be configured for smoke and/or heat, with a choice of EN54-approved sensitivities, and the device communicates bidirectionally with the SmartCell control panel on 868 MHz.

Key features

• Flexible detection: smoke and/or heat
• Integrated sounder with 32 selectable tones
• Integrated EN54-23 visual alarm device, red flash (category C-3-9.5)
• Fully wireless, quick and easy to install
• Inbuilt locking mechanism
• Batteries included

Technical specifications

• Smoke sensitivity: Normal (default), Normal + AVF
• Heat sensitivity: 58 °C static A2S (default), 58 °C rate of rise A2R, 72 °C static BS, 72 °C rate of rise BR
• Sound output: 93 dB(A) at 1 m max.
• VAD category: C-3-9.5 (red flash)
• Power supply: 3 x 3.6 V lithium thionyl chloride batteries (Fanso or HCB ER14505M), included
• Operating frequency: 868 MHz
• Output transmitter power: 14 dBm / 25 mW
• Signalling protocol: X5
• Operating temperature: -10 to +55 °C
• Storage temperature: -10 to +30 °C with batteries, -10 to +55 °C without
• IP rating: IP21C, Type A indoor use only
• Dimensions: 110 mm diameter x 61 mm depth
• Weight: 0.2 kg
• Approvals: EN54-3, EN54-5, EN54-7, EN54-13, EN54-23 and EN54-25 (CPR 0359-CPR-00268)
