Fike CIE-A-400 Addressable Repeater Panel (540-0010)

The Fike CIE-A-400 repeater panel (RDU-A-400, part 540-0010) is a remote display unit for the Fike CIE-A-400 addressable fire alarm control panel.

It shows system status at a secondary location, using the same menus as the control panel, and has its own built-in power supply requiring a mains supply and standby batteries.

Key features

• Connects to the CIE-A-400 panel over a multi-drop RS-485 peripheral bus
• Up to 8 repeaters per control panel, all within 500 m total bus length
• Same menu structure as the control panel
• Built-in PSU with battery charger
• Key switch or access code to enable fire alarm controls
• Configured from the main panel (Peripheral Bus Settings: RDU setup and initialise RDUs)

Technical specifications

• Part number: 540-0010 (CIE-A-400 Repeater)
• Mains supply: 230 V AC, 3 A fused unswitched spur, separate circuit from the CIE
• Batteries required: 2 x 12 V 7 Ah sealed lead acid
• Operating voltage: 21 to 33 V
• Operating current at 32 V: quiescent 30 mA, maximum 60 mA
• Communications: multi-drop RS-485
• Total peripheral bus length: 500 m
• Maximum repeaters per control panel: 8
• Cable: 2-core 1.5 mm² screened fire-rated
• Dimensions: 353 x 333 x 117 mm
• IP rating: IP30
• Operating temperature: -5°C to +40°C
