The FireAngel CW1-PF-T is a 230V mains-powered carbon monoxide alarm with a replaceable 9V battery back-up and FireAngel's push-fit base for quick first-fix and second-fix installation. Its electrochemical sensor is calibrated and tested in CO gas to measure low levels of CO and give the earliest warning. It is intended for any room with a fuel-burning appliance and main living spaces, and can be hardwire interlinked with up to 12 SW1-PF-T smoke, HW1-PF-T heat and CW1-PF-T CO alarms, or interlinked wirelessly using the RF-BW-T base.
Key features
- 230V mains powered with 9V battery back-up
- Electrochemical CO sensing, calibrated and tested in CO gas
- Improved push-fit base for quicker installation; align the arrows for a secure connection
- Hardwire interlink up to 12 smoke (SW1), heat (HW1) and CO (CW1) units: when one sounds they all sound
- Wireless interlink option using the RF-BW-T base
- Large central test button
- LED indicators for power, fault and alarm; low battery warning
- Safety clip prevents the alarm being fitted without a battery
- Dust cap supplied to protect the alarm during building work
Technical specifications
- Model: CW1-PF-T
- Sensor type: electrochemical
- Power: 230V AC mains with 9V PP3 zinc carbon battery back-up
- Alarm sound level: 85dB at 3m
- Installation position: ceiling
- Dimensions: 126mm diameter x 49mm depth
- Operating temperature: 0°C to 40°C
- Maximum hardwired interlink: 12 units
- Approvals: EN 50291-1:2018
- Warranty: 5 years
