Global Fire OWL Graphical Software - 1 Panel (Online) (OWL-1-ONLINE)

Global Fire OWL is fire alarm management and monitoring software for Global Fire Equipment's Chameleon Network range of intelligent fire alarm control panels. This is the online 1 panel licence (OWL-1-ONLINE). OWL's graphical interface shows every device, alarm and status across the whole system on floor plans, so operators can see exactly where a fire or fault is and respond in real time.

Key features

• 'Plug and play' monitoring and control software with a graphical user interface
• Devices (loops, zones, texts and device types) imported from the control panel configuration file
• Drag and drop icon placement for device location mapping on floor plans
• Events shown on floor plan layouts with flashing icons marking the affected area
• Basic commands from the main page: activate sounders, silence sounders, silence buzzers and system reset
• Enable/disable field devices; view real-time device conditions and analogue values
• Global event log and selectable event notifications by email and SMS
• Two user level groups (admin and operator); English and Portuguese languages

Technical specifications

• Licence: 1 panel
• Compatible panels: OCTO+, GEKKO, NODE+, G-One
• Capacity: up to 64 systems and up to 16,000 connected devices; up to 5 simultaneous users
• Communication interface: TCP/IP (INT-TCP IP-ODY)
• Set-up: connect the panel to the PC over TCP/IP and import the .gfd file exported from the Chameleon Connector software
• Operating system: Windows 7 and above
• Hardware: 2GHz processor (min.), 4GB RAM, 1GB hard disk
• Screen resolution: 1280 x 720 (min.) to 2560 x 1440 (max.)
• Image formats: bmp, jpg and others
