The HAES RECARD-TMR is an 8 A double-pole PCB-mounted changeover relay card with a programmable timer. It can work as a delay timer of 0–255 seconds, minutes or hours, or as a pulsing relay with individually set on and off times. It runs on 24 V DC and is supplied with nylon self-adhesive mounting pillars.
Key features
- 8 A double-pole changeover relay, contacts rated at 250 V AC
- Delay timer mode: 0–255 seconds, minutes or hours
- Pulsing relay mode: on and off times individually set from 0–255 seconds
- Two-colour relay status LED
Technical specifications
- Operating voltage: 24 V DC nominal
- Contact rating: 250 V AC 8 A, double-pole changeover
- Quiescent current: 7.5 mA
- Activated current: LED only 24 mA; LED + buzzer 38 mA; LED + relay 43 mA; LED + buzzer + relay 57 mA
What's in the box
- Relay card
- Nylon self-adhesive mounting pillars
