The Haydon HAY-EXT120IRHDMI is an HDMI extender kit that sends 4K HDMI video and audio up to 120 metres over a single Cat5e or Cat6 cable. Supplied as a transmitter and receiver pair, it is a cost-effective way to place a monitor well away from a DVR, NVR or other HDMI source. Cat6 cable is recommended.
Key features
- Extends HDMI up to 120m over one Cat5e/Cat6 cable (Cat6 recommended)
- Supports resolutions up to 4K, plus 1080p, 720p, 576p/i and 480p/i
- Audio formats supported: DTS, Dolby and LPCM
- Maximum bandwidth 340MHz
- Transmitter (TX) and receiver (RX) units, each powered by a 5V DC 1A adaptor
- HDMI input and output leads up to 15m (AWG26 standard HDMI cable)
Specification
| Product code |
HAY-EXT120IRHDMI |
| Brand |
Haydon |
| Transmission distance |
Up to 120m over Cat5e/Cat6 |
| Max resolution |
4K |
| Power |
5V DC 1A adaptor (100-240V AC input) |
| Current |
TX 350mA max, RX 200mA max |
| Operating temperature |
-15 to +55 C |
| Humidity |
5 - 90% RH, non-condensing |
| Dimensions (L x W x H) |
94 x 84 x 24mm |
| Weight |
223g per unit |
