The HKC 12/24V RF access keypad with prox is a weatherproof wireless access control keypad for homes and commercial buildings, with a built-in proximity reader for tags. It uses HKC SecureWave wireless technology to work with the SW-10270 panel. It can also run standalone with the HKC RF-RBX wireless relay box, which needs a 12V supply.
Key features
- Up to 250 unique entry codes, plus proximity tag reading
- Permanently powered from an external 12 to 24V DC or 18 to 24V AC supply
- Standalone option with the RF-RBX wireless output relay box
- Wireless link means no lock cables to short out
- Can also be used to set the alarm system and confirm exit/entry
- On-board request-to-exit input
- Programmed locally with SmartLink700 (SL700), including in standalone mode
- IP67 rated and weatherproof
Technical specifications
- Input power: 12 to 24V DC or 18 to 24V AC
- Current at 12V DC: standby 100mA (default), 30mA (no backlight), maximum 250mA
- Wireless range: more than 400m line of sight
- Maximum users: 250
- Dimensions: 124 x 87 x 31mm
- Weight: 195g
- IP rating: IP67
- Operating temperature: -25°C to +60°C
