Name: Knight Fire D702 G2 Large Surface Contact, 6-Screw, DPST, White
Brand: Knight Fire & Security
SKU: D702
Price: 5.80 GBP
Availability: InStock

Knight Fire D702 G2 Large Surface Contact, 6-Screw, DPST, White

Roll over image to zoom in Click on image to zoom

D702 is a 6-screw large surface contact complete with a leaf tamper switch. Wiring points are 4x switch & 2x tamper. This double reed variant operates in DPST configuration, allowing two separate circuits to be switched simultaneously. See code D70 for the single reed, SPST variant.

Fitting screws supplied.

Main Features

6-Screw (4x Switch, 2x Tamper)
DPST Operation
Leaf Tamper
Large Housing
Made in UK
Environmental Class II

Specifications

Application/Usage	Door; Window
Connectivity Technology	Wired
Contact Type	Form A (SPST-NO)
Energy Star	No
Environmental Certification	Environmental Class II (Indoor Uncontrolled)
Indoor/Outdoor	Indoor
Input Voltage	100V DC; 120V AC
Limited Warranty	1-Year
Material	Plastic
Mount Type	Surface Mount
Package Contents	6-Terminal Industrial Double Reed With Tamper Fixing Screws
Product Line	Surface Contact
Product Series	D
Product Type	Surface Contact
Security Grade	Grade 2
Standard Gap	40.00mm
TAA Compliant	No
ATEX Compliant	No
CE Marking	Yes
CNBOP Certified	No
Colour	White
Contact Material	Rhodium
INCERT Certified	No
Input Current	500mA
LPCB Certified	No
Manufacturer	Knight Fire & Security Products Ltd
NF Certified	No
NF&A2P Certified	No
RoHS Compliant	Compliant
SBSC Certified	No
TIA Listed	No
UL Listed	No
VdS Certified	No
WEEE Compliant	Compliant
