Power Sonic 12v 12Ah Sealed Lead Acid Battery - Flame Retardant (PS-12120FR)

The Power Sonic PS-12120FR is a 12V 12Ah sealed lead acid (SLA) battery from Power Sonic's PS Series general purpose range, in the flame retardant (FR) version with a UL94 V-0 rated ABS case and cover. It is built for float and light cyclic use, and suits fire and security systems, emergency lighting, UPS and medical devices.

Key features

• Absorbent Glass Mat (AGM) sealed lead acid construction, maintenance free
• Gas recombination technology for quick recovery of capacity during charge
• Flame retardant ABS case and cover rated UL94 V-0
• 5 year float life class (per Power Sonic float life data)

Technical specifications

• Model: PS-12120FR
• Nominal voltage: 12V (6 cells)
• Nominal capacity (20 hour rate): 12.0Ah
• Capacity (10 hour rate): 11.2Ah
• Capacity (5 hour rate): 10.35Ah
• Capacity (1 hour rate): 7.2Ah
• Internal resistance (approx.): 19 mΩ
• Max short circuit discharge current: 336A
• Dimensions (L x W x H): 151 x 98 x 95mm (±2mm)
• Height over terminals: 101mm
• Approximate weight: 3.24kg
• Operating temperature, charge: -20°C to +50°C
• Operating temperature, discharge: -15°C to +60°C
