The Texecom Capture CQ-W is a Grade 2 wireless ceiling-mount quad PIR motion detector with omni-directional 360° coverage, using Texecom's Ricochet mesh wireless technology for commercial-grade wireless performance with Texecom intruder alarm systems. It has the same form factor as its wired Capture counterpart and suits retail and office applications. This listing is the black version (GDD-0006).
Key features
- 9.3 m / 360° coverage
- Quad element pyro for true 360° pick-up
- Optional low sensitivity mode
- EN 50131-2-2 Grade 2; entire coverage pattern independently certified to EN 50131-2
- Ricochet mesh wireless with automatic wireless set-up
- Laser-etched instructions
- Tri-colour LED
- Lifetime warranty (battery 24 months)
Technical specifications
- Part number: GDD-0006 (black)
- Detection: quad PIR, 9.3 m at 360°
- Mounting: ceiling, 2.4 m to 3.6 m
- Maximum current: 18 mA; quiescent current: 21 µA
- Frequency: 868 MHz (868.2–868.4 MHz); max RF power 10 mW; listen-before-talk receiver
- Operating voltage: 3 V; supplied battery capacity 1250 mAh
- Low battery signal: 2.85 V; detector operates for at least 30 days after low battery is signalled
- Operating temperature: -10°C to +55°C; humidity 0–95% non-condensing
- Dimensions: 125 mm diameter x 43 mm deep
- Weight (with ring and battery): 167 g
