| Application/Usage |
Network PoE devices such as wireless access points, IP cameras, VoIP phone systems, IPTV decoders, access controls and more |
| Compatibility |
PoE (15.4W), PoE+ (30W) or PoE++ (90W) devices |
| Data Transfer Rate |
10Gbps |
| Depth |
109.7mm |
| Features |
10GBASE-T compliant; Auto-sensing technology delivers correct wattage; IEEE 802.3af/at/bt compliant; Magnetic wall-mount design; NDAA / TAA compliant; Network a PoE device up to 100m (328 ft.) over Cat6A or better cabling; Supplies PoE (15.4W), PoE+ (30W) or PoE++ (90W) |
| Height |
28.6mm |
| Limited Warranty |
3-Year |
| Maximum Data Transfer Rate |
10Gbps |
| NDAA Compliant |
Yes |
| Number of Network (RJ-45) Ports |
2 |
| Output Power |
90W |
| Package Contents |
Power adapter (54V DC, 1.67A); Quick Installation Guide; TPE-318GI |
| PoE Budget |
90W |
| Power Consumption |
0W |
| Power Source |
DC Power |
| Product Series |
Version V1 |
| Product Type |
PoE++ Injector |
| TAA Compliant |
Yes |
| Weight |
672.00g |
| Width |
70.0mm |
| Maximum Operating Temperature |
50°C |
| Certifications & Standards |
CE; FCC; IEEE 802.3; IEEE 802.3ab; IEEE 802.3af; IEEE 802.3an; IEEE 802.3at; IEEE 802.3bt; IEEE 802.3bz; IEEE 802.3u |
| Dimensions |
109.7mm x 70mm x 28.6mm |
| Maximum Distance |
100.0m |
| Minimum Operating Temperature |
0°C |
| Number of Ethernet Ports |
2 |
| Operating Relative Humidity (H-H) |
90% (Non-condensing) |
| Operating Temperature (T-T) |
0-50°C |
| Power over Ethernet (PoE) |
Yes |
| RoHS Compliant |
Compliant |
| WEEE Compliant |
Out of Scope |
