| Data Transfer Rate |
10Mbps |
| Ethernet Technology |
1 Gbps (Gigabit Ethernet) |
| Features |
1 x Gigabit PoE++ input port; 10Gbps switching capacity; 4 x Gigabit PoE+ output ports; 60W PoE power budget with PoE++ Type 4 (95W) input power; Bandwidth control per port; Compact fanless design; Easy-to-use web-based management interface; Supports RSTP, VLAN, QoS and IGMP Snooping; Voice VLAN for VoIP applications; Wall-mountable metal housing |
| Limited Warranty |
Lifetime |
| Material |
Metal |
| NDAA Compliant |
Yes |
| Network Switch Type |
Managed |
| Number of Network (RJ-45) Ports |
5 |
| Number of Ports |
5 |
| Package Contents |
Quick Installation Guide; TPE-B541 |
| PoE |
Yes |
| PoE Budget |
60W |
| Product Series |
V1 |
| Product Type |
Managed Switch |
| Status Indicators |
LED indicators |
| TAA Compliant |
Yes |
| Total Number of Network Ports |
5 |
| Weight |
450.00g |
| Buffer |
512KB |
| Certifications & Standards |
CE; FCC; IEEE 802.1d; IEEE 802.1p; IEEE 802.1Q; IEEE 802.1w; IEEE 802.3; IEEE 802.3ab; IEEE 802.3af; IEEE 802.3at; IEEE 802.3bt; IEEE 802.3u; IEEE 802.3x; LVD |
| Dimensions |
170mm x 105mm x 28mm |
| Interfaces/Ports Details |
1 eSATA interface; 1 RS-232; 1 RS-485; 16 Alarm In; 16 SATA interfaces; 2 x USB 2.0; 2 x USB 3.0; 9 Alarm Out |
| Layer Supported |
Layer 2 |
| Localization |
English |
| Manageable |
Yes |
| Maximum Power Consumption |
7.31W |
| MTBF |
503726hr |
| Networking Standards |
IEEE 802.1D; IEEE 802.1p; IEEE 802.1Q; IEEE 802.1w; IEEE 802.3; IEEE 802.3ab; IEEE 802.3af; IEEE 802.3at; IEEE 802.3bt; IEEE 802.3u; IEEE 802.3x |
| Number of Ethernet Ports |
5 |
| Operating Humidity |
90% (Non-condensing) |
| Operating Temperature (T-T) |
0-40°C |
| Power over Ethernet (PoE) |
Yes |
| RoHS Compliant |
Compliant |
| WEEE Compliant |
Out of Scope |
