Key featuresFull details
- 4000 Series module with touch free button
- Adjustable activation range from 3cm to 15cm
- Adjustable activation time from 0.5 to 20 seconds, or latch
- Status LED: red when powered and in standby, blue when activated
- Button electronics resin potted (IP65 rated button)
- For internal use, or protected from direct rain if used externally to avoid false triggering
| Available to order | Qty | Delivery |
|---|---|---|
| Pre-order | 0 | Lead time 2 to 6 weeks |
Videx 4000 Series Touch Free 1 Button Module
£46.05
Genuine stockBrand new, boxed
1 year warrantyPlus statutory rights
Secure checkoutEncrypted payments
Trade accounts30 day credit
Frequently bought together
Videx
Videx 4000 User 1 Relay Proximity Reader 12-24Vac/Dc
Sale price£115.15
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Videx
Videx 4204X-0/M 0-Button Functional Interface Speaker Module
Sale price£247.70
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Videx
Videx 4204X-1/M 1-Button Speaker Module with Proximity Reader for VX2200
Sale price£253.50
In stock
Videx
Videx 4204X-2/M 4000 Series 2-Way 2-Button Speaker Module for VX2200 Digital System with Integrated Proximity Access Reader, IP65, IK07, Marine Grade Stainless Steel, (Replaces 4203/2, 4204X-2)
Sale price£258.65
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Product details
The Videx 4840NT is a 4000 Series module fitted with a touch free infrared call button, part of the Videx NT touch free range. Visitors make a call by approaching the button with their hand, with no need to press it.
Key features
- 4000 Series module with touch free button
- Adjustable activation range from 3cm to 15cm
- Adjustable activation time from 0.5 to 20 seconds, or latch
- Status LED: red when powered and in standby, blue when activated
- Button electronics resin potted (IP65 rated button)
- For internal use, or protected from direct rain if used externally to avoid false triggering
Specification
| Product code | 4840NT |
|---|---|
| Brand | Videx |
| Range | 4000 Series / NT touch free series |
| Power input | 12Vdc |
| Current | 25mA standby, 37mA in operation |
| Relay | Dry contact output (CO, NO, NC), max. 1A @ 30Vdc |
| Button material | Black polycarbonate, fire and UV proof |
| Operating temperature | -20 to +75 deg C |
Datasheet
Videx 4000 Series Touch Free 1 Button Module Need the datasheet? Our team will email it to you. Request datasheet
Videx 4000 Series Touch Free 1 Button Module
£46.05
