The Videx VR4KIFM is a vandal resistant VR4K series information module for Videx audio and audio/video door entry panels. Its back-lit window holds a card insert that can be customised with a company name or logo, instructions, or a street name or number.
It is made from 316 marine grade stainless steel and fits the full range of 4000 series surface and flush back boxes and front support frames.
Key features
- Back-lit information window with blue LED
- Customisable white card insert
- 12 gauge (2.5 mm) 316 marine grade vertically brushed stainless steel fascia
- IK09 impact protection and IP55 ingress protection
- Compatible with all 4000 series surface and flush back boxes
Technical specifications
- Part number: VR4KIFM
- Window: transparent polycarbonate, 52 (W) x 84 (L) mm
- Card insert: 1 x white, 62 (W) x 100 (L) mm
- Illumination: 1 x blue LED
- Voltage input: 12 VDC (for back-light LED)
- Current rating: 30 mA
- Protection: IK09 impact, IP55 ingress (stainless steel fascia)
- Module size: 103 (W) x 120 (L) x 18 (D) mm (1 module 4000 series)
