The Zeta Xtratone MKII-AXT/R is a small, high output red addressable wall sounder for indoor use on Zeta Fyreye MKII protocol addressable fire alarm systems. It is designed to meet EN54 part 3, with 16 tones selectable from the control panel, and can be hard addressed with its DIP switch or soft addressed with the MKII handheld programmer.
Key features
- Complies with EN54 part 3
- 16 tones selectable from the control panel (approved tones: Tone 0 and Tone 8)
- Hard addressed via 8 way DIP switch or soft addressed via MKII handheld programmer
- 4 x 20mm cable entries (2 top, 2 bottom)
- Wire-to-back-box first fix
Technical specifications
- Part number: 42-610
- Colour: Red
- Operating voltage: 17-28V DC
- Quiescent current: 1.5mA
- Alarm current: 5.4mA
- Sound output: 99.3dB ±2dB (Tone 0, reverberant conditions)
- Operating temperature: -10°C to +55°C
- Maximum humidity: 95% RH non-condensing
- IP rating: IP21C
- Size: 105 x 105 x 49mm (105 x 105 x 82mm with back box)
- Weight: 200g
