Description
This powerful camera delivers outstanding 4K and ultra-high light sensitivity. It's available with a wide lens for open areas or a tele lens for surveillance from a distance. Plus, with PoE out you can connect and power an additional device.
Excellent forensic details and powerful performance
Featuring a 4/3"image sensor, AXIS Q1808-LE offers exceptional low-light performance. And, thanks to Lightfinder 2.0 it ensures true colors in almost complete darkness. In addition, adeep learning processing unit (DLPU)lets you run advanced features and powerful analytics on the edge. It offers improved processing and storage capabilities so you can collect and analyze even more data than before. Plus, it delivers valuablemetadatafacilitating fast, easy, and efficient forensic search capabilities in live or recorded video.
Great coverage in wide, open areas
With a wide (12 - 48 mm) Canon lens and 90°-21° horizontal field of view, AXIS Q1808-LE is perfect for surveillance in wide, open areas. It offers 4x zoom and outstanding light sensitivity to ensure excellent forensic details. Plus, white light IR LEDS (850 nm) let you switch to white light to deter unwanted activity.
Excellent details at great distances
With a tele (50 - 150 mm) Canon lens and 21°-7° horizontal field of view, AXIS Q1808-LE is perfect for great details at long distances. With an additional 3x zoom, it's ideal for identification purposes. Plus, Optimized IR allows for surveillance in complete darkness up to 120 m (394 ft) without the need for extra lighting.
Enjoy big savings
Not only does this powerful camera deliver outstanding 4K details, but thanks toZipstreamH.264/ H.265, it also significantly reduces bandwidth and storage requirements. And, with storage profile enabled, you'll enjoy the optimal level of Zipstream for your video storage - regardless of yourVMS. Even at night, when images contain a high level of noise, this powerful camera ensures low bandwidth and great details. In addition, PoE out lets you connect and power another device without any additional cabling. This eliminates the need to rent extra ports and simplifies installation. For instance, you can easily connect a horn speaker, strobe siren, or even another camera. Furthermore, dynamic power mode together with low power profile reduces power demands by as much as 50% in certain temperature ranges.
- Network camera - Helps achieve high-quality video results
- Up to 3712 x 2784 video resolution
- Features RGB CMOS sensor
- Up to 120 m of night vision
- Infrared night vision type efficiently detects infrared waves that are invisible to the naked eye
- Auto camera iris is ideal for outdoor video surveillance as it adjusts the iris according to changing light conditions and high-contrast situations
- PoE power source type for your network camera provides maximum energy feasibility and added surveillance productivity
- Wide Dynamic Range feature for maximum productivity with added dependability
- Wired connectivity technology offers maximum visual convenience
Specifications
| Connectivity Technology | Wired |
|---|---|
| Depth | 385.0mm |
| Diameter | 183.0mm |
| Durability | Impact Resistant |
| Effective Camera Resolution | 10MP |
| Environmental Certification | IEC 60068-2-1; IEC 60068-2-14; IEC 60068-2-2; IEC 60068-2-27; IEC 60068-2-6; IEC 60068-2-78; IEC/EN 60529 IP66; IEC/EN 60529 IP67; IEC/EN 62262 IK10; NEMA 250 Type 4X; NEMA TS 2 (2.2.7-2.2.9) |
| Environmentally Friendly | Yes |
| Features | Excellent details at great distances; Excellent forensic details and powerful performance; Great coverage in wide, open areas; Reliable and robust |
| Field of View | Horizontal; Vertical |
| Focal Length | 12-48mm |
| Form Factor | Bullet |
| Image Sensor Type | CMOS |
| Indoor/Outdoor | Outdoor |
| Ingress Protection Rating | IP66; IP67 |
| Input Voltage | 10V DC; 20V AC; 24V AC; 28V DC |
| Lens Type | Varifocal |
| Limited Warranty | Not provided |
| Maximum Aperture | f/4 |
| Maximum Focal Length | 48.0mm |
| Maximum Resolution | 1280 x 720 |
| Mount Type | Conduit Box Mount; Corner Mount; Pole Mount |
| Network (RJ-45) | Yes |
| Night Vision | Yes |
| Night Vision Type | Infrared (IR) |
| Optical Zoom | 4x |
| Package Contents |
|
| Package Type | Box |
| Product Line | Q |
| Product Series | Q18 |
| Product Type | Fixed cameras |
| Storage Type | SD Card |
| TAA Compliant | Yes |
| Video Resolution | 1280 x 720 |
| Weight | 32000.00g |
| Wide Dynamic Range | Yes |
| Maximum Operating Temperature | 60°C |
| Aperture | f/1.7- 4.0 |
| Colour | White |
| Country of Origin | PL |
| Impact Protection Rating | IK08; IK10 |
| Lens Included | Yes |
| Longest Shutter Speed | 2 Second |
| Manufacturer | Axis Communications |
| Maximum Frame Rate | 60fps |
| Maximum Power Consumption | 51W |
| Memory Card Supported | Yes |
| Minimum Focal Length | 12.0mm |
| Minimum Illumination | 0.00lux |
| Minimum Operating Temperature | -40°C |
| Night Vision Distance | 120.00m |
| Operating Humidity | 5-95% |
| Power over Ethernet (PoE) | Yes |
| Remote Management | Yes |
| RoHS Compliant | Compliant |
| Shortest Shutter Speed | 1/45500s |
| Supported Network Protocols | IPv6 |
| Video Formats | H.264 / AVC; H.265 / HEVC; MPEG-4 Visual; MPEG-H |
| WEEE Compliant | Compliant |
