The C-TEC BF359/3CL is a camlock kit for C-TEC's BF359/3 flush stainless steel anti-tamper enclosures: the BF359/3S (shallow), BF359/3M (medium depth) and BF359/3D (deep). These enclosures house SigTEL ECU controllers, XFP 32 zone fire panels, AFP fire panels and Quantec QT601-2 controllers, and each one needs a lock kit, which is supplied separately. The BF359/3CL provides a key-operated camlock, and the kit also includes a stainless steel pull knob that can optionally be fitted to the door.
Key features
- Key-operated camlock for BF359/3S, BF359/3M and BF359/3D enclosures
- Adjustable lock keeper plate fitted to the enclosure back box to suit the turn of the camlock
- Optional 30mm stainless steel pull knob for the enclosure door
- Allen key included for fitting
Technical specifications
- Compatibility: C-TEC BF359/3S, BF359/3M and BF359/3D enclosures
- Camlock type: C330
- Pull knob: stainless steel, 30mm diameter
- Alternative lock kit: BF359/3SL electromagnetic solenoid lock kit
What's in the box
- 1 x C330 camlock with hex nut
- 1 x lock keeper plate
- 1 x stainless steel knob (30mm) with M4 x 10 pozi pan screw, M4 spring washer and penny washer
- 2 x M5 x 8 socket cap head screws, 2 x M5 square spring washers and 2 x M5 plain washers
- 1 x 4mm short arm Allen key
