The C-TEC ECU723 is an optional interface/network communication card for C-TEC's SigTEL disabled refuge / emergency voice communication system. It mounts inside an ECU-4, ECU-8 or ECU-16 controller and lets an ECU-224 desk controller be connected to simplify call handling on larger SigTEL installations. It can also network the controller to other SigTEL controllers. It is not compatible with ECU-8NT controllers.
Key features
- Connects an ECU-224 desk controller to an ECU-4, ECU-8 or ECU-16 controller
- Can also network the controller to another SigTEL controller
- Speech carried on a single wiring loop, digital data on two linear RS485 networks
- Cat 5 patch lead supplied to connect the card to a master controller
Technical specifications
- Compatibility: SigTEL ECU-4, ECU-8 and ECU-16 controllers (not ECU-8NT)
- Connections: Cat 5 to the master controller; Cat 5 to the ECU-224 desk controller
- Network cable: 4 x 2-core 1.5mm² enhanced fire-rated cable
- Dimensions: 92mm (W) x 108mm (H) x 20mm (D)
- Weight: 56g
