Electro Detectors Zerio Plus Wireless Input / Output Unit with SMA for External Antenna (EDA-T6085)

The Electro Detectors EDA-T6085 is the Zerio Plus radio input/output unit with an SMA connector for an external antenna. It gives two monitored inputs and a set of clean NO/NC relay contacts on the Zerio Plus wireless fire alarm system, and the external antenna option helps where the unit sits in a poor radio location. It is certified to EN 54-25.

Key features

• Radio I/O unit with SMA connector for an external antenna
• 2 monitored inputs (second input enabled if specified when ordered)
• Set of clean NO/NC relay contacts that operate in alarm
• MOSFET switched output for AC or DC signals up to 40V 1A
• EN 54-25, fully addressable
• Supplied with transmitter, mounting box and battery

Technical specifications

• Part number: EDA-T6085
• Power source: dual lithium cells (2 x AA lithium)
• Battery life: 2–3 years
• Battery pack: 1 x EDA-Q690
• Inputs: 4K7 end-of-line, 470Ω fire load to alarm
• Relay supply: 6–40V DC required if the relay is used
• Transmitter frequency: 868MHz, narrow band FM, 13 channels
• Temperature range: 0 to +60°C
• Humidity: 0 to 95% (no condensation)
• Dimensions: 90 x 90 x 62mm (including base)
• Weight: approx. 200g (including base)
• Fixing: 4 x 4mm (No. 6) screws
