Global Fire ORION Repeater Panel c/w Network Card (ORION-REP)

The Global Fire Equipment ORION REP is a repeater panel for the GFE ORION conventional fire alarm control panel. It gives remote control, system status display and monitoring, and shows all Fire, Fault, Test and Disabled conditions in the same way as the ORION panel itself. It complies with EN 54-2.

It comes with an RS232 interface as standard and also works with GFE's other data loop interfaces, so it can be linked to the ORION panel over RS232, RS485, fibre optic or TCP/IP. Up to 4 repeaters can be connected to one ORION panel: one offers display and control, and the rest display only.

Key features

• Remote display of all Fire, Fault, Test and Disabled conditions
• User control at access levels 1 and 2; level 2 entered with the same four-digit code as the ORION panel
• RS232 interface included as standard
• Also works over RS485, fibre optic or TCP/IP interfaces
• Up to 4 repeaters per ORION panel (1 display and control, 3 display only)
• Available in white or red

Technical specifications

• Supply voltage: 28 V DC nominal, taken from the ORION auxiliary supply output
• Supply current: 40 mA
• Connections: +supply, -supply, TX and RX
• Repeater network: RS232, RS485, fibre optic or TCP/IP; 1 display and control plus 3 display only
• Operating temperature: 0°C to 40°C
• Humidity: 95% RH non-condensing
• Dimensions: 272 (W) x 404 (H) x 107 (D) mm
• Weight: 1.4 kg
• Standard: EN 54-2
