Kentec Safe-Point 16-Way Disabled Refuge Control Panel - Loop Wired - Surface Mounting (K41216SST)

The Kentec Safe-Point K41216SST is a 16-way disabled refuge (emergency voice communication) master control panel for surface mounting. It lets staff answer or call up to 16 Safe-Point disabled refuge outstations.

The outstations are wired to the master panel in a loop, which cuts installation time and cost. The cabinet has space for 7 Ah batteries, giving the 24 + 3 hours standby specified by BS 5839 Part 9. It has a stainless-steel fascia on a mild-steel back box.

Key features

• 16 call/answer outstation inputs, loop wired
• Simple handset operation with full-duplex conversation; calls end when the handset is replaced
• Call or answer each, several or all outstations from the fascia push buttons
• Alarm indicators with internal buzzer; power on and system fault indicators
• Lamp test and buzzer silence push button
• 'In Fire' enable input to prevent non-essential calls
• Integrated display for custom alarm information
• Tamper-resistant vision window cover
• Toilet alarm kits can be wired in line with a refuge call/answer point

Technical specifications

• Product code: K41216SST (surface, loop)
• Enclosure: stainless-steel fascia, mild-steel back box
• Surface back box: 500 (W) x 400 (H) x 100 (D) mm
• Weight: 5 kg
• Standby batteries (not supplied): 2 x 12 V 7 Ah sealed lead acid (Yuasa NP7-12)
• Mains supply: 220 to 240 V AC, 5 A lighting-rated supply; max. system load 40 W
• Loop cable: 4-core (+ screen) enhanced fire-rated cable, daisy-chained to each outstation
• Volt-free changeover contacts for remote fault reporting and for call indication
• Environment: indoor use, -10°C to +45°C, max. 95% RH; IP30
