Kentec Sigma CP Ancillary PCB Boxed

The Kentec K02000M2 is a boxed Sigma CP ancillary board. It adds volt-free fire, fault and coincidence relay outputs, plus zonal outputs, to a Kentec Sigma CP conventional fire alarm control panel. The board is in a steel enclosure styled to match the Sigma CP-R repeater. This version is powered from a 24 V DC supply.

It connects to the control panel over a two-wire RS485 serial link. Up to 7 ancillary boards can be connected to a panel, and they can be mixed with Sigma CP-R repeaters and sounder boards, up to 7 of each type. Each unit is given an address from 1 to 7 with a DIL switch. The data cable from the main panel to the last unit must not exceed 1200 m.

Key features

• Two-wire serial (RS485) connection to the Sigma CP panel
• Up to 7 boards per system
• Volt-free fire, coincidence and common fault relay contacts
• Zonal outputs for zones 1 to 8
• Address set by DIL switch; processor reset switch

Technical specifications

• Product code: K02000M2 (boxed, 24 V DC powered)
• Standby current: 20 mA; full alarm current: 190 mA
• Fire, fault, coincidence and zonal contact rating: 30 V DC 1 A
• Construction: 1.2 mm mild sheet steel, epoxy powder coated, IP30; BS 00 A 05 grey lid and box
• Size: 385 x 310 x 60 mm
• Weight: 1 kg
• Cable capacity: 2.5 mm² per terminal
• Operating temperature: -5°C to +50°C; humidity below 95% non-condensing
