Name: Talentum Flame Detector (I.S.) (16579-00)
Brand: Talentum
SKU: 16579-00
Price: 1417.50 GBP
Availability: PreOrder

FFE Fireray 5000 System (Long Range) (5000-113) - JEM Systems UK

Roll over image to zoom in Click on image to zoom

A Talentum 16000 series IR3 flame detector in the intrinsically safe (I.S.) version for hazardous areas. Three infrared sensors respond to different wavelengths of the flickering (1-15 Hz) radiation emitted by flames, discriminating between real fires and other radiation sources.

Key features

Triple IR (multi-spectrum) sensing with excellent immunity to false sources
Detects almost all flames, from hydrocarbon fires through to invisible hydrogen fires
Tolerant of fumes, vapours, dust and mist; suitable for indoor and outdoor areas
Selectable sensitivity and response speed
Programmable relay outputs - normally open or normally closed, latching or non-latching
Built-in automatic and manual test
Intrinsically safe design for use in hazardous areas

Specification

Product code	16579-00
Brand	Talentum
Detector type	IR3 (triple infrared) flame detector
Housing	Die-cast zinc alloy
Dimensions	142 (h) x 108 (w) x 79 (d) mm
Cable entries	2 x 20 mm
Supply voltage	14 to 30 Vdc
Quiescent current	3 mA to 8 mA
Alarm current	9 mA to 28 mA
Operating temperature	-10 to +55 °C
Relative humidity	95% non-condensing
Range (Class 1 / Class 3)	25 m / 12 m
Field of view	90° minimum cone
Operating wavelength	IR 1.0 to 2.7 micrometres
Approvals	EN, VdS, LPCB, ATEX

Genuine, brand-new products from leading fire and security manufacturers
UK trade fire and security distributor based in Poole, Dorset
Free UK delivery on orders over £150 (ex VAT)
Next working day delivery on Poole stock ordered by 1pm; 2-3 business days otherwise
Free collection from our Poole warehouse, Monday to Friday until 3pm
Trade accounts and project quotes: apply for a trade account
Technical help: call 0113 518 0540
