The Videx VR4KIND is a vandal resistant VR4K series induction loop module for Videx door entry panels. It connects directly to VR4K series speaker modules and lets people with a hearing aid set it to the T position to hear the conversation from the entry panel speaker.
It meets the Equality Act 2010 (UK) and the IEC 60118-4:2014 hearing loop performance standard, and fits the full range of 4000 series surface and flush back boxes.
Key features
- Induction loop for hearing aid users (T position)
- DDA compliant: Equality Act 2010 (UK) and IEC 60118-4:2014
- Automatic gain control adjusts to variations in input level
- Internal status LEDs
- 12 gauge, 316 grade brushed stainless steel fascia
- IK09 impact protection and IP55 ingress protection
- Compatible with all 4000 series surface and flush back boxes
Technical specifications
- Part number: VR4KIND
- Systems: multiple Videx audio and video systems
- Material: 12 gauge, 316 grade vertically brushed stainless steel
- Protection: IK09 impact, IP55 ingress
- Window: polycarbonate, 52 (W) x 84 (L) mm
- Status LEDs: LED1 red (power), LED2 green (signal active), LED3 red (audio overdrive)
- Power input: 13.8 to 14 VDC
- Current rating: 800 mA standby (1 A max.), up to 2 A during operation
- Module size: 103 (W) x 120 (L) x 36 (D) mm
