The Advanced MXP-635-P is the passive fibre optic converter for MxPro 5 and Axis EN fire panel networks. Used with SFP modules, it acts as a full fibre or hybrid copper/fibre modem for both radial and ring topology networks.
It is designed for reliable data communication and easy visual system diagnostics, improving the quality of service of critical communication networks while operating under the performance criteria required by BS 5839-1. (The active MXP-635-A version adds fibre optic system monitoring and reporting via the iView interface.)
Key features
- 2.5kV galvanic isolation on all ports
- Supports single and dual port industrial RS-485 connections
- Hot-swappable SFP modules: multi-mode (up to 2km), single-mode (up to 20km) or bi-directional (up to 20km)
- One modem routes both in and out ports, so only one is needed per panel
- Adjustable termination on ports B or C with RS-485 transceivers to match the loop cabling segment
- Single switch configuration for fibre optic or RS-485 media
- Simple LED status indication for fibre and RS-485
- Baud rate selectable from 9,600 to 115,200 bit/s
- Redundant power supply for increased reliability
- DIN rail mountable
- Compatible with MxPro 5 and Axis EN systems
Technical specifications
-
Operating voltage: 18-36V (24V DC nominal)
-
Rated current: 250mA at 24V
-
RS-485 ports: A1 and A2, selectable fixed termination (EIA RS-485)
-
Fibre optic / RS-485 ports: B and C fibre optic SFP connectors (to selected SFP transceiver specification); port C selectable fixed termination
-
Isolation: Ports A1, A2 isolated (2.5kV)
-
Baud rate: 9,600 to 115,200, selectable
-
USB: USB Micro-B (device/slave mode)
-
Operating temperature: -10°C to 50°C
-
Storage temperature: -40°C to 70°C
-
Dimensions: 115 x 105 x 58mm
-
Weight: 200g
-
Mounting: DIN rail EN 60715 (35mm)
-
Compliance: CE, UKCA, RoHS, WEEE; EMC EN 61000-6-2 and EN 61000-6-4; safety EN 60950
-
SFP modules (order separately): MXP-635-SM single-mode, MXP-635-MM multi-mode, MXP-635-BD/AB and MXP-635-BD/BA bi-directional
