The IBEX, model 700H, is Evac+Chair's two-person, tracked evacuation chair for spiral, narrow and winder staircases, where conventional evacuation chairs cannot be used. Evac+Chair previously sold it as the IBEX TranSeat and now markets it simply as the IBEX. Unlike descent-only chairs, it can move a seated passenger both up and down stairs. Two trained operators work together with its adjustable brake to control each step, and the track belt takes most of the passenger's weight, which reduces manual handling. It carries passengers of up to 159kg.
Key features
-
Stair ascent and descent: suitable for upward evacuation as well as downward.
-
Adjustable track brake: set it to suit the passenger's weight for a controlled, step-by-step descent.
-
Track belt system: rests on the stair nosings to help control the speed and smoothness of travel.
-
Telescopic handle: extends or retracts so that the lead operator can work at a comfortable height.
-
Front grab handles: give the second operator a secure hold during ascent and descent.
-
Stainless steel frame: strong and durable construction.
-
Detachable seat and backrest: easy to clean and to replace if worn or damaged.
-
Passenger safety: adjustable chest straps and a foot strap.
Specifications
-
Payload capacity: 159kg
-
Chair weight: 14.5kg (unladen)
-
Folded (H x W x D): 1140 x 465 x 400mm
-
Unfolded (H x W x D): 1470 x 465 x 785mm
-
Stair angle: 28° to 40°
-
Operators: two trained operators required
-
Direction of travel: stair ascent and descent
-
Suitable for: spiral, narrow and winder staircases, including those in historic and space-restricted buildings
-
Approvals: CE and UKCA marked, registered Class 1 medical device, manufactured under ISO 9001 and ISO 13485
What's included
- Wall bracket
- Dust cover
- User guide
Training
Evac+Chair International states that its evacuation chairs must only be used by trained operators. Operator or Key Trainer certification is valid for two years, and regular practice drills are recommended so that staff stay competent.
Warranty
Evac+Chair provides a five-year manufacturer's warranty against defects in materials and workmanship. Wear parts such as the tracks are excluded, and the warranty conditions in the user guide apply.
