The Fike Sita 403-0007-NC is the IP65 weatherproof Sita addressable manual call point for Fike Duonet, Quadnet and CIE-A-200/400 addressable fire systems, supplied without the protective call point cover.
It lets occupants raise the fire alarm manually in exposed or damp locations. Once operated it latches into alarm until reset with the special key.
Key features
- Addressable manual call point that connects directly to the loop
- Built-in short circuit isolator
- Resettable element latches when operated and does not need replacing; reset with the special key
- Soft addressed: address allocated automatically by the control panel during initialisation
- Test by pressing the element; LED indicates activation
- IP65 weatherproof housing; fit IP68 cable glands to maintain the rating
- Supplied without call point cover (NC version)
Technical specifications
- Part number: 403-0007-NC (Sita weatherproof MCP 403-0007, no cover)
- Surface depth: 70 mm
- IP rating: IP65
- Dimensions: 87 x 87 mm
- Operating temperature: -10°C to +50°C
- Voltage range (loop): 24 to 42 V DC
- Loop current: quiescent 0.18 mA; alarm 2.89 mA
- DLU rating: 3
- Flammability: UL94-V2
- Standards: EN 54-11, EN 54-17
- System compatibility: Duonet and Quadnet V1 onwards; CIE-A-200 V1 onwards
- Cable: 2-core 1.5 mm² screened fire-resistant, wired as a loop (no spurs)
