The Fike Twinflex 402-0007-NC is the weatherproof Twinflex manual call point for Fike Twinflex 2-wire fire alarm control panels, supplied without the protective call point cover.
It is a 2-wire, zone-powered call point that can share a zone with Twinflex multipoint detectors and sounders. Once operated it latches into alarm and is reset with the special key; the resettable element does not need replacing.
Key features
- Zone-powered manual call point for Twinflex 2-wire systems
- Resettable element latches in alarm; reset with the key
- Built-in end-of-line function, enabled by DIL switch on the last device
- IP65 rated for weatherproof use; fit suitable cable glands to maintain the rating
- Alarm LED pulses twice per second
- Supplied without call point cover (NC version)
Technical specifications
- Part number: 402-0007-NC (Twinflex weatherproof MCP 402-0007, no cover)
- Dimensions: 87 x 87 mm; surface depth 70 mm
- Operating temperature: -10°C to +50°C
- Voltage: 25.5 to 35 V DC (mains-powered panel); 20 to 26 V DC (battery-powered panel)
- Current: quiescent 50 µA; alarm 16.5 mA
- Loading: 3.0 SLU (V3 panel) / 16 DLU (Pro/Pro² panel)
- IP rating: IP65 (not EN 54-11 tested)
- Flammability: UL94-V2
- Cable: 2-core 1.5 mm² screened fire-resistant, radial circuit
